Firewolf 24V Commercial Intelligent Addressable Fire Panel, NFPA72-compliant, up to 96 outputs, 4 onboard NACs (6.5A total), expandable to 24, built in Sync/Strobe/Horn Module (System Sensor & Wheelock) and dual line DACT plus optional TCP/IP reporting. Features remote Smoke Obscuration Reporting. Nearly a mile., max. wire run – any wire type –ideal for retrofits. Also supports legacy and conventional (12V)devices, too and more of them per loop! Powerful battery capacity up to 32Ah total.

SeminarsGEM-C Combination Burglary/Access/ Fire System; UL 864, 9th Edition - Award Winning System Judged to be the Best in Fire/Life Safety by SIA 2011 Isolated commercial Burg./Access and Fire buses and option for separate burg/access battery backups-- easy calcs., ideal for AHJs. No costly extra Bus Isolator or Loop Isolator modules required! Integrates with GeminiAccess ACM Module. Uses familiar Quickloader Up/downloading and Gemini style keypads in burglary or fire models..

  • More zones – 255, 128 or 32 points
  • More power – 7 amps
  • More NAC's – Up to 4 on board
  • Built in strobe/horn synch
  • More standby power
  • 32 Amp hour battery capacity
  • Regulated 24V output
Gemini-C Commercial Addressable/Conventional 255-Zone Burglary System; Supports full line of new GEMC Commercial-rated conventional, addressable or wireless devices simultaneously on from 8 to 255 zones, with partitioning. UL Merchantile.

New Gemini Commercial Addressable Intrusion Systems for 128 and 255 Points of Protection

  • New Larger GEMC-Series Addressable Burglary Security Systems Kits offer up to 128 or 255 Points, respectively, ideal for larger commercial installations, such as schools, hospitals and institutions
  • Simultaneous support of with multi-technology devices for labor and equipment savings - Addressable (24V), UL Commercial wireless and 12V conventional devices, the latter, for retrofitting or upgrading older systems without replacing legacy installed wired devices, i.e., smoke detectors, PIRs, etc.
  • Very communicative, flexible reporting – Dual DACT onboard, TCP/IP Ready and StarLink Commercial Cellular Reporting and up/downloading (CDMA or GSM 3/4G)
  • Both high-value, preconfigured models include: Menu-Driven Alpha Keypad with 4-zones onboard, 4A/24V Power Supply, 2 high-speed serial ports and a merchantile locking enclosure for flush or surface mount, accommodates 16Ah batteries.
  • Fully code-compliant: UL 864 9th Ed, SIA CP01, UL985
  • Added by popular demand, 96-Point System also (still available, GEMCBURG96KT). New Models: 128 Point Intrusion System Kit GEMC-ADBRG128 or 255 Point Intrusion System Kit GEMC-ADBRG255, respectively.

NAC Extender provides nearly 7A and 4 onboard NACs with up to 2A ea; up to 16Ah total battery capacity. Easily distributes synched bell and strobe outputs with built in module. Monitors AC, battery trouble, tamper and ground fault on Napco bus or provides universal FACP support.

Regulated Auxiliary Power Supplies
Commercial burglary or fire, 12V regulated 2A models (fire shown); or 1.75A version with plug-in transformer. Backward compatible with all Gemini Panels. Alarm panel supervised power option. Ideal for simultaneous powering of CCTV cameras.

Firewolf Advanced Analog Addressable Commercial Fire Devices support auto-drift compensation and maintenance alert function

Gemini-C Addressable Commercial Burglary Devices permit longest loop length, upto 10,000 feet; no repeaters necessary!

Gemini-C UL Commercial Wireless Line with supervised tamper & automatic, continuously supervised signal strength (requires no manual test activation).

Gemini-C Burglary & Firewolf Menu-Driven Custom Alpha Keypads Familiar Napco ez-programming. Keypads mount anywhere on the bus. Burg model with integral 4-zone EZM.

NetLink Internet/Intranet TCP/IP Digital Communications Module For GEMC Gemini Commercial and Firewolf Systems secure, encrypted full reporting - eliminates the cost of two dedicated phone lines. UL864 9th ed. compliant. (Note: This is the commercial version of GEM-NLMOD used for standard GEMP816-X255 Systems.)

GEMC-ADBRG128 Gemini-C Burglary-Only Configuration, Commercial Conventional/ Addressable 128-Zone System

  • Supports full line of new GEMC Commercial-rated addressable, conventional or wireless devices simultaneously
  • 8 to 128 fully-configurable zones, with up to 7 partitions
  • Familiar Napco Quickloader up/downloading and keypad operation
  • Dual line DACT on board Agencies
Gemini-C Burglary-Only Configuration, Commercial Conventional/ Addressable 255-Point System
Similar to above, but

  • Supports 8 to 255 points of GEMC Commercial-rated addressable, conventional or wireless devices simultaneously

Compliances - NFPA 72, UL Commercial Fire, UL864 9th Ed., SIA CP01, UL985. UL household & commercial burg.: UL1610, UL609, UL365, UL1023. CSFM (fire).

NAPCO COMMERCIAL COMBO FIRE/BURG KITS ORDERING INFORMATION

GEMC-COMBO255KT 255 Point GEM-C Commercial Combo. Fire/Burg System Kit
  • 24V Panel, 255 Points via commercial addressable, wireless or conventional fire or burg. devices, 4 on board NACs, 8 partitions (No Loop Isolator/Extender required)
  • 7 Amp, 24V Power Supply
  • Burg. Module, with power supply with built in bus isolator for complete separation of fire and burg power and battery standby operation
  • Built in horn/strobe synch. module on each NAC
  • Built in dual line communicator; dual onboard serial ports
  • Quickloader up/downloading including remote smoke obscuration reporting
  • Locking, Large Red Enclosure, 16 x 25" reversible door, with 14.25" x 25" base. Houses up to 32Ah battery backup.
  • Menu-driven LCD Fire Keypad mounts anywhere on bus (Also, full keyswitch support)
GEMC-COMBO128KT 128 Point GEM-C Commercial Combo. Fire/Burg System Kit
As above, but with

  • 24V Panel, 128 Points via commercial addressable, wireless or conventional fire or burg. devices, 4 on board NACs, 8 partitions (No Loop Isolator/Extender required)
GEMC-COMBO32KT 32 Point GEM-C Commercial Combo. Fire/Burg System Kit
Similar to above, but with

  • 24V Panel, 32 Points via commercial addressable, wireless or conventional fire or burg. devices, 2 on board NACs, 8 partitions (No Loop Isolator/Extender required)
  • Locking, Medium Red Enclosure, 16 x 17" door, with 14.25" x 16" base. Houses up to 16Ah battery backup.

NAPCO COMMERCIAL FIRE KITS ORDERING INFORMATION

GEMC-FW-255KT 255 Point GEM-C Firewolf 24V Commercial Fire System Kit
  • 24V Panel, 255 Points via commercial addressable, wireless or conventional fire devices, 4 on board NACs providing up to 6.5A notification power
  • 7 Amp, 24V Power Supply
  • Built in horn/strobe synch. module on each NAC
  • Built in dual line communicator; dual onboard serial ports
  • Quickloader up/downloading including remote smoke obscuration reporting
  • Locking, Large Red Enclosure, 16 x 25" reversible door, with 14.25" x 25" base. Houses up to 32Ah battery backup.
  • Menu-driven LCD Fire Keypad mounts anywhere on bus. (Also, full keyswitch support)
GEMC-FW-128KT 128 Point GEM-C Firewolf 24V Commercial Fire System Kit
As above, but with

  • 24V Panel, 128 Points via commercial addressable, wireless or conventional fire devices, 4 on board NACs providing up to 6.5A notification power
GEMC-FW-32KT 32 Point GEM-C Firewolf 24V Commercial Fire System Kit
Similar to above, but with

  • 24V Panel, 32 Points via commercial addressable, wireless or conventional fire devices, 2 on board NACs providing up to 4A notification power
  • Locking, Medium Red Enclosure, 16 x 17" reversible door, with 14.25" x 16" base. Houses up to 16Ah battery backup.

NAPCO COMMERCIAL BURGLARY KIT

GEMC-BURG96KT

96pt GEMC Addressable Commercial Burglary System Kit 24V Panel, 96 Points via commercial addressable, wireless or conventional burg. devices, 7 partitions
  • Locking, Medium White Enclosure, 16 x 17” door, with 14.25” x 16” base. Houses up to 16Ah battery backup.
  • 4 Amp, 24V Power Supply
  • Addressable SLC Burg Module, supports up to 96 addressable SLC burg devices (GEMC-BSLC)
  • Built in dual line communicator; dual onboard serial ports
  • Quickloader up/downloading
  • Menu-driven LCD Burglary Keypad with built-in 4 zone EZM, mounts anywhere on bus (GEMC-BK1)
Gemini-C Burglary-Only Configuration, Commercial Conventional/ Addressable 128-Zone System
  • Supports full line of new GEMC Commercial-rated addressable, conventional or wireless devices simultaneously
  • 8 to 128 fully-configurable zones, with up to 7 partitions
  • Familiar Napco Quickloader up/downloading and keypad operation
  • Dual line DACT on board Agencies
Compliances

NFPA 72, UL Commercial Fire, UL864 9th Ed., SIA CP01, UL985.
UL household & commercial burg.: UL1610, UL609, UL365, UL1023. CSFM (fire).
