Intrusion

Expandable Gemini hybrid controls feature:

  • Wide choice of designer keypads for every application and budget
  • iBridge App & Touchscreen/Tablet for integrated security, climate, lighting or video control or iRemote Virtual Keypad App for smartphones/devices
  • Control4® Certified SDDP and Ethernet Integration C4 Controller can seamlessly use all Napco Bus detected activity for triggering home automation.
  • Support all major communication formats plus internet & StarLink Wireless Radios, universal primary/backup communicator (hi-speed up/downloads from Gemini Panels)
  • Up/downloading, including unique PC-preset unattended method
  • EZ-Programming mode at keypad
  • Choice of Gemini RF receivers & transmitters
  • Multi-stage lightning protection
  • Event log with open/closes suppression
  • Telco line cut supervision
  • Fuseless, maintenance-free operation
  • Transformer, supplied

Gemini X255 is the expansive hardwire/wireless control offering 255 fully-programmable zones, 195 users, fuseless operation & supports the full line of top performing Gemini Wireless

Features:
  • 8 to 255 hardwired zones or wireless zones/pts
  • Expandable using 8-zone GEM-EZM8 expansion modules
  • Up to 96 fire zones, with 8 2-wire fire zones
  • Up to 8 areas
  • Up to 195 user codes with open/close by user
  • 3 On-board relay output & 1 prog. lug
  • Up to 96 relays
  • Supports 4 wireless receivers
  • Supports 15 GEMRP1CAE2 or K1CA keypads
  • Up to 2 interior bypass groups
  • 800 Event log w/ open/close suppress
  • Auto arm/disarm
  • 255 Event scheduler
  • GEM-ACCESS access control compatibility

Gemini P9600 powerful multi-tasking hybrid control panel feature-rich for security applications and home automation integration

Features:
  • 8 to 96 hardwire zones/points
  • Including 8 2-wire fire zones
  • Up to 96 user codes
  • Up to 8 areas
  • 3 On-board relay outputs; expandable to 96
  • 1 On-board programmable lug
  • Up to 4 RF receivers
  • Up to 15 keypads
  • Up to 2 interior bypass groups
  • 800 Event log
  • Auto arm/disarm
  • 255 Event scheduler
  • GEM-ACCESS access control compatibility

Gemini P3200, a popular, all-around 8 zone hybrid control expandable to 32 zones or 48 wireless points

Features:
  • 8 to 32 hardwire or wireless zones/points;
  • up to 48 RF wireless points
  • Including 2 2-wire fire zones
  • Up to 48 user codes
  • Up to 2 areas
  • Fuseless, maintenance-free operation
  • 3 On-board relay outputs; expandable to 24
  • 1 On-board programmable lug
  • Up to 2 RF receivers
  • Up to 7 keypads
  • Interior bypass groups
  • 800 Event log
  • Auto arm/disarm
  • 255 Event scheduler
  • GEM-ACCESS access control compatibility

Gemini P1664, 4-area hybrid panel with 8-64-zones of power; supports all keypads plus talking multifunction keypads with built in siren & pet PIR

Features:
  • 8 to 64 hardwire or wireless zones
  • Up to 64 fire zones, with 2, 2-wire fire
  • Up to 64 user codes
  • Up to 4 areas
  • 400 event log; viewable at custom alpha keypads
  • Up to 2 RF receivers
  • EZ Programming at keypad and Auto Arm
  • Supports up to 7 keypads: all standard Gemini Keypads and/or talking, multifunction GEM-K1VPS (may be intermixed)
  • Supports 3 outputs; expandable up to 16 external outputs (RB/RM3008)
  • 2 PGM outputs
  • 1 interior zone group; 2 prog. chimes by zone;
  • SIA CP01 features

Gemini P1632, ultra-popular hardwire/wireless control panel with partitioning easy to standardize for both residential & light commercial applications

Features:
  • 8 to 32 hardwire zones/points
  • Including 2 2-wire fire zones (7;8)
  • EZ programming at keypad
  • Up to 32 user codes
  • Up to 2 areas
  • Supports up to 7 keypads and/or talking, multifunction GEM-K1VPS (may be intermixed)
  • 3 On-board relay outputs; expandable to 8 relay outputs
  • Up to 2 RF receivers
  • Interior bypass groups
  • 400 Event log
  • Auto arm

Gemini P816, an economical hardwire/wireless control panel that works seamlessly with all standard Gemini keypads and wireless

Features:
  • 8 to 16 hardwire zones/points
  • Including 2 2-wire fire zones
  • Up to 16 user codes
  • Supports up to 7 keypads
  • EZ Programming at keypad
  • 256 event logging
  • Supports 2 Gemini receivers
  • Interior bypass group
  • Auto arm
  • 3 Outputs

Gemini P801, economical 9 zone hybrid with your choice of numeric or custom alpha keypads

Features:
  • 9 Programmable zones: 6 Hardwire or wireless zones plus 2 wireless zones plus 2-wire fire zone
  • Use 2 optional zones at GEMRP8LCD custom alpha keypad
  • For Control packed with RP8LCD Custom Alpha Keypad, order GEM-P801ALPHA
  • For control packed with RP8 Numeric LED Keypad, order GEM-P801
  • Uses GEMRECVXP8 wireless receiver
  • 8 Individually reporting user codes
  • 50 Event log
  • Line and bell-cut supervision
  • Double reporting & backup reporting
  • EZ wire full-size terminal strips

Gemini P800, ultra-affordable hybrid control includes numeric keypad and 6 zones plus fire and panic

Features:
  • 8 programmable zones, including 2-wire fire zones
  • Up to 16 Gemini wireless points: 8 wireless points from your choice of Gemini PIR, window/door & glassbreaks
  • Up to 4 Gemini wireless smoke detectors and 4 GEMKEYF fobs
  • 8 individually reporting user codes
  • Supports up to 4 GEM-RP8 keypads &/or
  • 2 wireless receivers (GEM-RECVXP8)
  • Supports GEM-R8LCD/K800 Custom Alpha Keypad
  • Includes control, Numeric LED Keypad and transformer

Gemini Accessories

GEM-EZM4/8 Expansion Module
  • Economy 4 to 8 zone expansion module supports GEM-P816, GEM-P1632 & GEM-P1664
GEM-EZM8 Expansion Module
  • Eight-zone expansion module (for all expandable GEM panels. Audible find mode)

IBRIDGE REMOTE Z-WAVE MODULES

IBR-ZREMOTE (hardwire model)
IBR-ZREMOTE-W (WiFi model)
  • For Use with Gemini Panels
  • Use with iBridge Connected Home App (Free in iTunes and Google Play)
  • Adds Remote Services & Z-Wave Device Control in one easy module
  • Supports standard Z-Wave Devices and provides superior range
  • Choice of models - Connect with hardwire or WiFi for simple installation
  • Include 12 Mos. Subscriber Service
IREMOTEMOD/12

Gemini Virtual Keypad module provides a mirror-image, fully-functional, remote control keypad on a on any PC or smartphone online anywhere in the world (free apps for all smart devices.) Module simulates real keypad model at physical premises and simply wires on GEM-Panel's keypad bus.

GEM-TEMP64

    Indoor/Outdoor Temperature Sensor provides Temperature Display at any Gemini Alphanumeric Keypad in a GEMP1632 and GEMP1664 System. Keypad will show Temperature in display, from -30 to 60C or -22 to 140F (replacing "Date" on keypad-display), e.g., GEMK1VPS, GEM-DK1CA, GEM-K1CA, GEM-RP1CAe2. Module is mounted inside or outdoors, to display either the temperature outside or inside room temperature.

GEM-PRINT
  • Module that enables Gemini system activity to print to an on-site parallel printer
  • For use with GEMP816 to X255 Controls

Express Systems with multilingual LED XP keypads

XP400WK, XP600WK, respectively
  • Feature-rich programmable zones:
  • 4 in XP400 -or- 6 in XP600
  • Support all Gemini wireless transmitters
  • Using Gemini GEM-RECVXP8
  • Includes multilingual LED keypad (suffix –SN for Spanish language zone dir'y); RP-X4 for XP400 or backlit RP-X6 for XP600
  • Keyfob support: 2 or 4, respectively
  • Plus 4 or 8 pts, respectively, for RF points from choice of PIR, window/door & glassbreaks
  • Plus XP600's 2-wire fire zone also supports 4 wireless Gemini smoke detectors
  • 4 or 6 Individual user codes, respectively
  • Available in 4-Paks with 4 keypads, part no. XP400/4 or XP600/4

All Gemini HYBRID CONTROLS FEATURE:

  • Multiplex expandability using built-in EZMs in custom alpha keypads or 8-zone expansion modules (except GEM-P800)
  • Up/Downloading, including unique PC-preset unattended method
  • EZ-Programming mode at keypad
  • Choice of Gemini RF receivers & transmitters
  • Multi-stage lightning protection
  • Event log with open/close suppression
  • NetLink intranet/internet alarm reporting option
  • X-10 Support with optional GEM-X10 interface
  • Telco line cut supervision
  • Support for VOIP (voice over internet protocol) communications
  • Support all major communication formats & secondary pager format
  • SIA CP01 compliant versions available
  • Include transformer
